🏃 SONOFF SNZB-03PR2 — SenseGuard Motion Gen2 Zigbee PIR Motion Sensor
The upgraded Gen2 of our best-selling Zigbee motion sensor. The SONOFF SNZB-03PR2 is a Zigbee 3.0 PIR motion sensor with a wider 120° detection angle, 6 metre range, an adjustable sensor head and an independent lux sensor with up to 6 months of illumination history. Adjustable cooldown (5–60 s) cuts false triggers. Up to 3-year battery life (CR2477 included). Mounts with the magnetic base, screws or adhesive. Works with eWeLink, Alexa, Google Home, Home Assistant and Apple Home via a Matter bridge hub. MPN: SNZB-03PR2.
Which motion sensor do you need?
⚡ Key Features
- Wider 120° Detection Angle — covers more of the room than the Gen1's 110°; 6 m PIR range with fast ~5-second response
- Adjustable Sensor Head — aim the detection zone exactly where you want it; pairs with the included magnetic base for easy repositioning
- Adjustable Cooldown (5–60 s) — tune how often the sensor re-triggers to minimise false activations and save battery
- Independent Lux Sensor — light-based automations with calibration and up to 6 months of illumination history
- 3-Year Battery Life — single CR2477 coin cell (included); low-battery alert in the eWeLink app
- Smart Scene Automations — "Motion detected → lights on", "No motion for 5 minutes → lights off", "Motion after 10 PM → security alert"
- Local Zigbee Scenes — motion-to-light automations keep working through your hub even when the internet is down
- Flexible Mounting — magnetic attachment, screws or adhesive; walls, ceilings or shelves at any angle
- Home Assistant — supported in ZHA and Zigbee2MQTT; exposes occupancy, battery and illuminance (lux) entities
🏠 Perfect For
Automatic Hallway Lights
Walk past → lights on. Leave → lights off after your chosen timeout. The adjustable head lets you aim the zone down a passage precisely.
Security Alerts
"Motion in the garage after 11 PM → push notification + camera recording." Combine with SNZB-04P door sensors for a complete Zigbee security zone.
Lux-Aware Lighting
Only trigger lights when it's actually dark — the calibrated lux sensor plus illumination history makes day/night automations reliable.
Office Energy Saving
No motion in the meeting room for 15 minutes → lights and aircon off. The longer cooldown options reduce pointless re-triggers.
🔄 Gen1 vs Gen2 Comparison
| Feature | SNZB-03PR2 (This Product) | SNZB-03P (Gen1) |
|---|---|---|
| Detection Angle | 120° | 110° |
| Detection Range | 6 m | 6 m |
| Sensor Head | Adjustable orientation | Fixed |
| Cooldown | Adjustable 5–60 s | Fixed |
| Light Sensor | Yes + 6-month history | Yes (lux) |
| Mounting | Magnetic / screws / adhesive | 3M tape / screw / bracket |
| Battery | CR2477 — up to 3 years | CR2477 — up to 3 years |
📡 Compatible Zigbee Hubs
The SNZB-03PR2 requires a Zigbee 3.0 hub. Here are the hubs we stock:
SONOFF ZB Bridge-P
Affordable Zigbee-to-WiFi gateway. Supports up to 128 devices via eWeLink. The easiest way to get started with Zigbee sensors.
View Product →SONOFF NSPanel Pro
Wall-mounted touchscreen with built-in Zigbee hub, intercom, and dashboard. Manage all your sensors from one screen.
View Product →SONOFF ZBDongle-Max
Long-range USB Zigbee coordinator with external antenna and 2.5× range. Ideal for large homes with Home Assistant.
View Product →SONOFF ZBDongle-LMG21
Compact USB Zigbee coordinator for Home Assistant. Full local control via ZHA or Zigbee2MQTT.
View Product →📋 Technical Specifications
| Product | SONOFF SenseGuard Motion Gen2 Zigbee PIR Motion Sensor |
| MPN / Model | SNZB-03PR2 |
| Detection Type | PIR (Passive Infrared) — movement only |
| Detection Range | 6 metres |
| Detection Angle | 120° |
| Response Time | ~5 seconds; adjustable 5–60 s cooldown |
| Light Sensor | Yes — independent lux sensor, calibration, up to 6 months history |
| Battery | CR2477 (3V) — up to 3 years (included) |
| Protocol | Zigbee 3.0 (IEEE 802.15.4) |
| Hub Required | Yes — NSPanel Pro, ZB Bridge-P, iHost, ZBDongle-E/Max/LMG21 |
| Apple Home | Via Matter bridge hub |
| Home Assistant | ZHA · Zigbee2MQTT — occupancy, battery, illuminance |
| Voice Control | Amazon Alexa · Google Assistant (via hub) |
| App | eWeLink (iOS & Android) |
| Mounting | Magnetic attachment · Screws · Adhesive; adjustable head |
| Dimensions / Weight | 44 × 44 × 65 mm · 42.7 g with battery |
| Operating Temp | -10°C to +60°C · 5–95% RH non-condensing |
| Warranty | 1 Year Manufacturer Warranty |
❓ Frequently Asked Questions
What's new vs the SNZB-03P?
Will it detect my pets?
Will the lights stay on if I'm sitting still?
Does it work with Home Assistant?
Does it work outdoors?
